| Specification |
0.5 HP Pump |
1 HP Pump |
| Power |
0.5 HP (~370W) |
1 HP (~750W) |
| Voltage |
220–240V, 50Hz (Single Phase) |
220–240V, 50Hz (Single Phase) |
| Max Head |
28 – 35 m |
35 – 50 m |
| Max Flow Rate |
25 – 80 L/min |
100 – 120 L/min |
| Suction Lift |
7 – 8 m |
7 – 9 m |
| Inlet/Outlet Size |
1″ × 1″ |
1″ × 1″ (some models larger) |
| Pump Body Material |
Cast Iron / Thermoplastic |
Cast Iron |
| Impeller Material |
Brass / Stainless Steel |
Brass / Stainless Steel |
| Motor Winding |
100% Copper |
100% Copper |
| Protection |
Insulation Class B/F, IP44 |
Insulation Class B/F, IP44 |
| Applications |
Small homes, garden watering, shallow wells |
Large homes, farms, irrigation, deeper wells |
|
|
|
|
|
|
